Net Power – ISO 9249: 133 hp

Net Power – ISO 9249 (DIN): 134 hp (metric)

Engine Model: Cat C3.6

Our Engine Power – ISO 14396: 134 hp

Engine Power – ISO 14396 (DIN): 136 hp (metric)

Bore: 4 in

Stroke: 5 in

Displacement: 220 in³

Biodiesel Capability: Up to B20¹

Meets U.S. EPA Tier 4 Final, EU Stage V, Japan 2014 emission standards.

Note (1)

Net power advertised is the power available at the flywheel when the engine is equipped with fan, air intake system, exhaust system and alternator with engine speed at 2,200 rpm. Advertised power is tested per the specified standard in effect at the time of manufacture.

Note (2)

¹Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) or ULSD blended with the following lower-carbon intensity fuels** up to: 20% biodiesel FAME (fatty acid methyl ester)* or 100% renewable diesel, HVO (hydrotreated vegetable oil) and GTL (gas-to-liquid) fuels. Refer to guidelines for successful application. Please consult your Cat dealer or “Caterpillar Machine Fluids Recommendations“ (SEBU6250) for details. * Engines with no aftertreatment devices can use higher blends, up to 100% biodiesel (for use of blends higher than 20% biodiesel, consult your Cat dealer).** Tailpipe greenhouse gas emissions from lower-carbon intensity fuels are essentially the same as traditional fuels.

Main System – Maximum Flow: 296 L/min (78 gal/min)

Maximum Pressure – Equipment: 5075 psi

The Maximum Pressure – Travel: 5075 psi

Maximum Pressure – Swing: 3741 psi

Operating Weight: 40200 lb

Fuel Tank Capacity: 71.6 gal (US)

Cooling System: 5.8 gal (US)

Engine Oil: 2.9 gal (US)

Final Drive – Each: 1.6 gal (US)

Hydraulic System – Including Tank: 24.8 gal (US)

Hydraulic Tank: 23 gal (US)

DEF Tank: 5.9 gal (US)

Boom: Reach 5.1 m (16’9″)

Stick: Reach R2.9 m (9’6″)

Bucket: GD 0.76 m³ (0.99 yd³)

Shipping Height – Top of Cab: 9.6 ft

Handrail Height: 9.7 ft

Shipping Length: 28.1 ft

Tail Swing Radius: 8.2 ft

Counterweight Clearance: 3.3 ft

Ground Clearance: 1.4 ft

Track Length: 13 ft

Length to Center of Rollers: 10.4 ft

Track Gauge: 6.5 ft

Transport Width: 8.8 ft

Maximum Digging Depth: 21 ft

Boom: Reach 5.1 m (16’9″)

Stick: Reach R2.9 m (9’6″)

Bucket: GD 0.76 m³ (0.99 yd³)

Maximum Reach at Ground Level: 29.6 ft

The Maximum Cutting Height: 29.2 ft

Maximum Loading Height: 20.6 ft

Minimum Loading Height: 6.5 ft

Maximum Depth Cut for 2440 mm (8 ft) Level Bottom: 20.3 ft

Maximum Vertical Wall Digging Depth: 16.3 ft

Minimum Working Equipment Radius: 9.7 ft

Bucket Digging Force – ISO: 27650 lbf

Stick Digging Force – ISO: 16860 lbf

Standard and optional equipment may vary. Consult your Cat dealer for details.

5.1 m (16’9″) Reach Boom

CAB

Rollover protective structure (ROPS)

Air suspension heated seat, 10″ touch screen monitor

VisionLink

Remote Flash

Remote Troubleshoot

Cat Grade with 2D

The Cat Assist

Cat Payload

Work tool recognition

Work tool tracking

Auto hammer stop

Maintenance free battery

LED chassis light, left-side/right-side boom lights, cab lights

Programmable time-delay LED working lights

Cat C4.4 single turbo diesel engine

One-touch low idle with automatic engine speed control

Automatic engine shutdown

Electric fuel priming pump

Two-stage fuel filtration system with water separator and indicator

Sealed double element air filter with integrated precleaner

Electric cooling fans

Biodiesel capability up to B20

Boom and stick regeneration circuit

Auto hydraulic warm up

Auto two speed travel

Electric main control valve

Boom and stick drift reduction valve

Element-type main hydraulic filter

Single-type electronic main pump

Rear and right-side-view cameras

Ground-level engine shutoff switch

Service platform with anti-skid plate and countersunk bolts

Signaling/warning horn

Hydraulic lock out lever

2D E-Fence

Side entry to service platform

Grouped engine oil and fuel filters

Ground-level engine oil dipstick

Sampling ports for Scheduled Oil Sampling (S·O·S)

Grease lubricated track link

Tie down points on base frame
