310 Mini Excavator Inspired by Our Customers
The Cat® 310 Mini Excavator delivers maximum power and performance in a mini size to help you work in a wide range of applications. 310 Mini Excavator
Full Specifications of cat 310 excavator specs
Engine
Net Power: 69.5 hp
Stroke: 4.7 in
Note
Net power advertised is the power available at the flywheel when the engine is equipped with air cleaner, exhaust system and fan.
Bore: 3.7 in
Displacement: 203 in³
Gross Power – SAE J1995:2014: 74.3 hp
Engine Model – U.S. EPA Tier 4 Final/EU Stage V: Cat® C3.3B
Net Power – 2,200 rpm – ISO 9249:2007, 80/1269/EEC: 69.5 hp
Note 1
Advertised power is tested per the specified standard in effect at the time of manufacture.
Weights and cat 310 excavator price
Operating Weight: 23002 lb
Minimum Operating Weight with Cab*: 21170 lb
Maximum Operating Weight with Cab**: 23002 lb
Note (2)
**Maximum Weight is based on steel tracks with rubber pads, counterweight, operator, full fuel tank, long stick, blade and no bucket.
Note (1)
*Minimum Weight is based on steel tracks, no counterweight, operator, full fuel tank, long stick, blade and no bucket.
Travel System CAT 310 for sale
Maximum Traction Force – Low Speed: 19064 lb
Maximum Traction Force – High Speed: 6497 lb
Travel Speed – High: 2.9 mile/h
Travel Speed – Low: 1.6 mile/h
Ground Pressure – Maximum Weight: 5.9 psi
Ground Pressure – Minimum Weight: 5.4 psi
Gradeability – Maximum: 30 degrees
Hydraulic System
Operating Pressure – Swing: 3336 psi
Digging Force – Bucket: 17459 lb
Operating Pressure – Travel: 4134 psi
Operating Pressure – Equipment: 4134 psi
Note
Flow and pressure are not combinable. Under load, as flow rises pressure goes down.
Digging Force – Stick: 11060 lb
Type
Load Sensing Hydraulics with Variable Displacement Piston Pump
Pump Flow at 2,400 rpm: 62 gpm
Maximum Auxiliary Circuit – Secondary – Flow at Pump: 9 gpm
Our Maximum Auxiliary Circuit – Primary – Pressure at Pump: 4134 psi
Maximum Auxiliary Circuit – Secondary – Pressure at Pump: 4134 psi
Maximum Auxiliary Circuit – Primary – Flow at Pump: 35 gpm
Dimensions – Standard Stick
Tail Swing without Counterweight: 70.9 in
Stick Length: 98.4 in
Boom In Reach: 83.3 in
Maximum Reach: 303 in
Dig Depth: 205.2 in
Ground Clearance – Frame: 14 in
O/A Track Width: 97.2 in
Cab Height: 100 in
Track Belt/Shoe Width: 17.7 in
Maximum Blade Depth: 18.8 in
Our Maximum Dump Clearance: 229.5 in
The Maximum Dig Height: 313.8 in
Maximum Blade Height: 16.6 in
Tail Swing – Standard Counterweight: 76.1 in
O/A Undercarriage Length: 126 in
Vertical Wall: 172.6 in
Swing Bearing – Height: 28.9 in
Maximum Reach – Ground Level: 298 in
Overall Shipping Length – with Counterweight: 274.9 in
Note (2)
**Boom Height when stick is pinned in working position with attachments.
Note (1)
*Boom Height when stick is pinned in transport position (if available) with no attachments.
Overall Shipping Length – without Counterweight: 269.7 in
Height – Boom Transport – No Tools*: 100.4 in
Height – Boom Working – With Tools**: 106.3 in
Standard Equipment CAT 310 mini excavator price
ENGINE
Cat C3.3B Diesel Engine (U.S. EPA Tier 4 Final/EU Stage V) – Electronic Engine, Turbo, Diesel Particulate Filter (DPF)
Automatic Engine Idle
Our Automatic Engine Shutdown
The Automatic Swing Brake
Automatic Two Speed Travel
Fuel Water Separator with Indicator
Radial Seal – Double Element Air Filter
Extended Life Coolant, –37° C ( –37° F)
HYDRAULICS
Electronic Variable Displacement Piston Pump
Load Sensing/Flow Sharing Hydraulics
Power On Demand
Hydraulic Temperature Monitoring
Certified Accumulator
HYDO Advanced Hydraulic Oil
OPERATOR ENVIRONMENT
TOPS – ISO 12117:1997
ROPS ISO 12117-2:2008
Stick Steer Mode
Travel Cruise Control
Control Pattern Changer
Adjustable Wrist Rests
Molded Footrests
Removable, Washable Floor Mat
Travel Pedals and Hand Levers
Cat Key with Passcode Option
HVAC with Automatic Temperature Control
Hydraulic Lockout Controls
Integrated Lower Front Window
Assisted Front Window Overhead Storage
Rear Window Emergency Exit
Fabric, High Back, Suspension Seat
Retractable Seat Belt (75 mm/3 in)
Coat Hook
Cup Holder
LED Interior Light
Literature Holder
Mounting Bosses for Top and Front Guards
12V Power Socket
Radio – Bluetooth, Auxiliary, Microphone, USB (charging only)
Skylight
Signaling/Warning Horn
Cab and (left side) Boom Work Lights
Utility Space for Mobile Phone
Next Generation Color LCD Monitor (IP66)
– Jog Dial Interface
– Fuel Level and Coolant Temperature Gauges
– Maintenance and Machine Monitoring
– Performance and Machine Adjustments
– Numeric Security Code
– Multiple Languages
– Camera Ready (IP68 & IP69K)
– Hour Meter with Wake Up Switch
UNDERCARRIAGE
Greased and Lubricated Track
Tie Down Eyes on Track Frame
Dozer Straight Blade
Dozer Float
Bolt-on, Reversible Wear Edge
BOOM, STICK AND LINKAGES
One Piece Boom (4300 mm/169.3 in)
Front Shovel Capable – Pin-on/Manual Coupler/Hydraulic Coupler for Cat Tools (not available in all regions)
Thumb Ready (not available in all regions)
ELECTRICAL
12 Volt Electrical System
90 Ampere Alternator
900 CCA Maintenance Free Battery
Battery Disconnect
Ignition Key Stop Switch
Travel Alarm
Rear Camera
OTHER
Locks on External Enclosure Doors
Lockable Fuel Cap
Beacon Socket
Rear Reflectors
GUARDING
Roll Over Protective Structure (ROPS) ISO 12117-2:2008
Top Guard ISO 10262:1998 (Level I)
